Your Concrete Projects

The start of every successful concrete project involves careful planning and follow-up, whether you handle the project yourself or hire a concrete contractor.

Involving a professional concrete contractor may be wise if the project is very large or complicated. Hiring a contractor also relieves the home or property owner of a lot of the planning, preparation and direct project management. However, if a contractor is used, be sure to request and receive lien waivers, from all contractors and sub-contractors involved, upon payment and completion of the project. If the contractor fails to pay the suppliers for materials or services on your project, they are still entitled to file a lien against your property for the price of their product or service to ensure payment.

If you choose to handle your project yourself we offer the following suggestions:

Concrete Project Preparation

Concrete is an excellent construction material for many applications. The expected use of the concrete will help determine the required thickness and any special properties. The load carrying capacity of a slab is primarily dependent on thickness. A four-inch-thick slab will handle common weight loads such as foot traffic, light storage, cars, pickups, light tractors and animals. Whereas a six-inch-think slab will handle most medium-duty weight loads, such as motor homes, straight trucks and larger equipment. Reinforcement materials such as wire mesh, fibers or rebar add strength and durability to the slab and reduce cracking and shifting. Unusually heavy vehicles or high-traffic projects may require special design consideration.

Concreting tools commonly required are:

Start by removing all organic matter, such as grass, weeds, wood and any pockets of soft or water-soaked soil. In some cases, the slab can be placed directly on undisturbed soil. If any of the sub-grade or base has been disturbed, fill may be added to raise the final height of the slab and create uniform depth or thickness of concrete. Any fill should be placed on undisturbed soil and compacted in layers six inches thick or less. For soils with questionable drainage, such as clays or soft black dirt, use a fill base of four to eight inches of compacted sand or fine gravel to help disburse water and reduce settlement. Never place concrete on muddy or frozen ground.

Use 2x4s or 2x6s to form the parameter of the slab. The tops of the forms need to be set to the desired final height of the slab. Lumber should be straight and staked at two-foot intervals to minimize form bowing. After forming is completed, check the slab thickness. Using a stringline or straightedge across the top of the forms, measure the depth to the base or sub-grade. Pay careful attention to the depth or slab thickness. Variances as small as one inch can result in up to 25% more concrete being required, based on a four-inch-thick slab.

Check the weather forecast before ordering concrete. Ideal temperatures for placing concrete are between 50°F and 90°F. Warmer temperatures will make the concrete dry quicker, leaving less time to complete the job. Lower temperatures will lengthen the amount of time for the concrete to dry. Newly placed concrete should not be subjected to temperatures below 40°F for at least a week.

Sufficient manpower and tools should be ready before the concrete arrives. Ideally, concrete should be in place less than 90 minutes after batching at the ready-mix plant. Place concrete as close to its final position as possible, not in large piles. Screed the concrete using a sawing action pulling a straight board along the top of the forms. One of the most common mistakes at the job site is adding too much water to the concrete mix. This is done to change the consistency of the concrete, but should be done sparingly. Too much water can reduce strength and durability, leading to the formation of shrinkage cracks.

After the concrete is in place, the surface needs to be finished. Finishing involves settling the aggregate and removing surface imperfections. Start by using a bull float, this helps to push the aggregates below the surface allowing for subsequent finishing activities. A wooden or metal hand float or trowel is used to remove slight surface imperfections. An edger, which is like a short steel trowel with a rounded side, is used adjacent to the forms and along the parameter of the slab. When correctly used, an edger produces a more attractive rounded edge and can reduce chipping or breaking along the edge. Steel troweling follows floating and edging when a smooth, dense surface is desired. Timing is important in this operation because if delayed too long, the surface becomes too hard to trowel. All outdoor slabs subject to weather conditions should be broomed. Brooming the surface after floating or troweling is the last step in finishing that produces an abrasive, slip-resistant surface.

Concrete shrinks slightly as it dries. Once fully dried, seasonal changes in temperature cause the concrete to expand and contract, which can lead to cracking. Control joints are cuts in the surface of the slab approximately one-quarter of its thickness, purposely placed to position cracks in predetermined locations. Jointing tools can be used if done during finishing and saws with concrete or masonry blades enable you to cut control joints after the concrete has dried. A good rule of thumb for control joints is to double the thickness as feet. For example a four-inch-thick slab should have control joints placed every eight feet.

After the concrete has set for 12 or more hours, careful consideration should be given allowing it to “cure.” Fresh concrete should not be subjected to temperatures below 40°F for at least a week. When pouring concrete in cold weather, some type of insulation should be used to keep the concrete surface from freezing (e.g., insulation blankets or straw). Inversely, concrete should not be allowed to dry too quickly in very warm weather. When pouring concrete that is in direct sunlight with temperatures in excess of 90°F, it is recommended to keep the surface damp with a light water mist, dampened straw or flooding to enhance curing by supplying additional water.
